SY-609 EG

Product Series：Indicator Light

Release date：2024-12-27

Panel features:

1. Adopting dual passwords for more flexible use.

2. Undervoltage alarm, password input error 3 times alarm lock function.

3. Password is 3-8 digits long.

4. Support mute function, button sound can be freely turned on or off.

Technical parameters:

1. Working power supply: Four No. 5 "AA" alkaline batteries

2. Working voltage range: 4.0V to 6.8V

3. Undervoltage point at work 4.5V ± 0.2V

4. Working current: ≤ 380mA

5. Static current:< 15uA

6. Working temperature:- 10℃～+70℃

7. Working humidity: 10% to 90% RH
