SY-877

Product Series:Fingerprint

Release date:2024-12-27

Inquiry now



Panel features:

1. Adopting semiconductor fingerprint module, it is safer, more sensitive, has a high recognition rate, and consumes less power.

2. The panel aperture indicator is aesthetically pleasing and concise.

3. Undervoltage alarm, fingerprint verification error alarm 5 times.

4. Supports mute function, the sound can be freely turned on or off.



Technical parameters:

1. Working power supply: Four No. 5 "AA" alkaline batteries

2. Working voltage range: 4.5V to 6.8V

3. Undervoltage point at work 4.8V ± 0.30V

4. Working current: ≤ 380mA

5. Static current:< 25uA

6. Working temperature:- 10℃~+70℃

7. Working humidity: 10% to 90% RH
